2-2643-L
FA+ Series - 96% Efficiency Reflector
LED
FORTIMO SLM C 1210 L15 1919 G7N HE+
Diameter
75 mm
Hole
19.5 mm
Height
50.5 mm
FWHM
18°
LES
15.0
Material
AL
Fastening
Holder
Application
Spot Light
Remark
BJB 47.360.5080
Green Gems Gh36D-B40
Green Gems Gh36D-B40
Description
- Optional SPO or MIX optical microstructure lenses solve the problem of dark areas in traditional reflector apertures and control visual glare. Even with the addition of microstructure lenses, light output efficiency can still reach up to 94%.
- The FA series has a light output rate of up to 96%, while the FA+ series includes an aluminum fixing device that securely attaches to the bracket and saves installation time.
- Compatible with ZHAGA holder.
- This Series is designed for customers who demand high-quality light spots and efficiency.
- Available in various specifications, including D35, D45, D50, D63, & D75;
- Beam angles of 18°, 24°, 38°, & 50°
Product Video
Compatible LED
| Brand | LED | OD | Hole | H | FWHM | Accessory | |
|---|---|---|---|---|---|---|---|
| Lumileds | 1208 | 75 | 19.5 | 50.5 | 18° | 92.70.411.00 | |
| Lumileds | 1208 | 75 | 19.5 | 50.5 | 17° | 92.70.411.00 92.70.398.00 |
|
| Lumileds | 1205 | 75 | 19.5 | 50.5 | 17° | 92.70.411.00 | |
| Lumileds | 1205 | 75 | 19.5 | 50.5 | 17° | 92.70.411.00 92.70.398.00 |
|
| Bridgelux | V13B | 75 | 19.5 | 50.5 | 17° | 92.70.412.00 | |
| Bridgelux | V13B | 75 | 19.5 | 50.5 | 17° | 92.70.412.00 92.70.398.00 |
|
| Citizen | CLU038 | 75 | 19.5 | 50.5 | 17° | 92.70.412.00 | |
| Citizen | CLU038 | 75 | 19.5 | 50.5 | 17° | 92.70.412.00 92.70.398.00 |
|
| Cree | CXA1830 | 75 | 19.5 | 50.5 | 17° | 92.70.429.00 | |
| Cree | CXA1830 | 75 | 19.5 | 50.5 | 17° | 92.70.429.00 92.70.398.00 |
|
| LEDTEEN | P2141-036-1206-P3090-1 | 75 | 19.5 | 50.5 | 19° | 92.70.412.00 | |
| LEDTEEN | P2141-036-1206-P3090-1 | 75 | 19.5 | 50.5 | 19° | 92.70.412.00 92.70.398.00 |
|
| Luminus | CXM-14-AC40 | 75 | 19.5 | 50.5 | 18° | 92.70.412.00 | |
| Luminus | CXM-14-AC40 | 75 | 19.5 | 50.5 | 18° | 92.70.412.00 92.70.398.00 |
|
| Nichia | NFCWJ108B-V3 | 75 | 19.5 | 50.5 | 18° | 92.70.411.00 | |
| Nichia | NFCWJ120B-V3 | 75 | 19.5 | 50.5 | 18° | 92.70.411.00 | |
| Nichia | NFCWJ130B-V3 | 75 | 19.5 | 50.5 | 18° | 92.70.411.00 | |
| Nichia | NFCWJ108B-V3 | 75 | 19.5 | 50.5 | 18° | 92.70.411.00 92.70.398.00 |
|
| Nichia | NFCWJ120B-V3 | 75 | 19.5 | 50.5 | 18° | 92.70.411.00 92.70.398.00 |
|
| Nichia | NFCWJ130B-V3 | 75 | 19.5 | 50.5 | 18° | 92.70.411.00 92.70.398.00 |
|
| Tridonic | SLE G7 15MM | 75 | 19.5 | 50.5 | 18° | 92.70.412.00 | |
| Tridonic | SLE G7 15MM | 75 | 19.5 | 50.5 | 18° | 92.70.412.00 92.70.398.00 |
|
| Philips | FORTIMO SLM C 1205 L15 1919 G7N HE+ | 75 | 19.5 | 50.5 | 18° | 92.70.412.00 | |
| Philips | FORTIMO SLM C 1208 L15 1919 G7N HE+ | 75 | 19.5 | 50.5 | 17° | 92.70.412.00 | |
| Philips | FORTIMO SLM C 1208 L15 2024 G7 HE+ | 75 | 19.5 | 50.5 | 18° | 92.70.411.00 | |
| Philips | FORTIMO SLM C 1205 L13 2024 G7 HE+ | 75 | 19.5 | 50.5 | 16° | 92.70.411.00 | |
| Philips | FORTIMO SLM C 1205 L13 2024 G7 HE+ | 75 | 19.5 | 50.5 | 17° | 92.70.411.00 92.70.398.00 |
|
| Philips | FORTIMO SLM C 1205 L15 1919 G7N HE+ | 75 | 19.5 | 50.5 | 18° | 92.70.412.00 92.70.398.00 |
|
| Philips | FORTIMO SLM C 1208 L15 1919 G7N HE+ | 75 | 19.5 | 50.5 | 18° | 92.70.412.00 92.70.398.00 |
|
| Philips | FORTIMO SLM C 1208 L15 2024 G7 HE+ | 75 | 19.5 | 50.5 | 18° | 92.70.411.00 92.70.398.00 |
